Easy to build and use
About Product
Display your TV as a flush-to-wall, floating screen setup with the Recessed TV Wall Mount (MOUNT-REC01) from VIVO! The in-wall design offers the convenience of an extending, articulating arm with the clean look of zero-gap mounting. When the arm is folded, cables are completely hidden to create a picturing-hanging style TV display. Extending a total of 30” from the wall, the arm creates comfortable viewing angles for the whole group to enjoy. The mounting bracket fits 50” to 75” flat are curved screens alike with VESA patterns from 200x100mm to 600x400mm. Solid steel design holds up to 110 lbs with ease, providing a secure hold for your large TV.
Compatibility
- Screen Sizes: 50” to 75”
- Screen Types: Flat and Curved
- Installation: Wood Stud, Concrete/Brick Wall Installation
- VESA Standard: 200x100mm, 200x200mm, 300x200mm, 400x200mm, 300x300mm, 400x300mm, 400x400mm, 600x400mm
- Weight Capacity: 110 lbs
Specifications
- Material: Steel
- Mounting Box Dimensions: 15.7” x 3.5” x 23.2”
- Max Arm Extension: 30”
- Articulation: +15° to -15° tilt, 180° swivel
- Profile: 1.1” (minimum distance from wall)
Assembly Instructions
